| Specification Parameters | |
| Nominal Capacity | 125Ah |
| Nominal Voltage | 3.22V |
| Initial IR | 0.40 mΩ ± 0.05 mΩ |
| Weight | 2390 g ± 71 g |
| Charging Cut-off Voltage | 3.65 V |
| Discharging Cut-off V oltage | 2.5 V T > 0℃) 2.0 V T ≤ 0℃) |
| Charging Temperature | – 10 ℃~65℃ |
| Discharging Temperature | – 35℃~65℃ |
| Storage Temperature | -20℃ ~ 45℃ |
| Model Name | LF125 |
| Cycle Life | 4000 Cycles |
| Standard Charging Current | 62.5 A |
| Standard Discharging Current | 62.5 A |
| Height(H) with terminal | 172.00 mm ± 0.50 mm |
| Height(h) without terminal | 169.30 mm ± 0.50 mm |
| Length | 200.70 mm ± 0.50 mm |
| Thickness | 33.25 mm ± 0.50 mm |
