Product Details
Cell Model: 40120 2.4V/10Ah
Battery Configuration: 5S2P/12V/10Ah
Nominal Voltage: 12V
Nominal Capacity: 10Ah
Charging Voltage: 14.25V
Charging Current: ≤2A
Discharge Current: 5A
Instantaneous Discharge Current: 15A
Discharge Cutoff Voltage: 7.5V
Product Internal Resistance: ≤150mΩ
Battery Weight: 1.4kg
Product Dimensions: 42 × 130 × 220 mm (Max)
Charging Temperature: -20～45℃
Discharging Temperature: -20～70℃
Storage Temperature: -20～45℃
Battery Case: PVC
Lithium Battery Protection: Short circuit protection, overcharge protection, over-discharge protection, overcurrent protection, etc.
Application Field: Outdoor power monitoring and communication battery
Main Features
Low Temperature Charging: Supports charging at -20℃
Wide Temperature Discharging: Discharges efficiently from -20 to 70℃
Safety and Long Cycle Life: Designed for high safety and long cycle life
Eco-Friendly: High cycle life, low carbon, energy-saving, and environmentally friendly design
