Product Details:
Cell Model: 18650-2200mAh-3.7V
Battery Specification: 18650-6S3P-6600mAh-22.2V
Product Size: 233*147*31mm (Max)
Nominal Voltage: 22.2V
Nominal Capacity: 6600mAh
Finished Product Internal Resistance: ≤200mΩ
Charging Voltage: 25.2V
Charging Current: ≤4A
Discharging Current: ≤4A
Discharge Cut-off Voltage: 16.5V
Battery Weight: 1000g
Charging Temperature: 0～45℃
Discharging Temperature: -30～60℃
Storage Temperature: -20～35℃
Battery Casing: Aluminum alloy casing
Lithium Battery Protection: Short circuit protection, overcharge protection, over-discharge protection, over-temperature protection, overcurrent protection, ESD protection, etc.
Application: Special equipment, portable exploration equipment backup power supply, low-temperature equipment field.
Features:
Metal Casing: Aluminum alloy casing for increased battery reliability and robustness.
Hardware Output Terminal: Gold-plated spring contact output for enhanced conductivity reliability.
Battery Management: Uses dedicated lithium battery protection chip for high stability, high-precision monitoring, precise control, with ESD protection and temperature protection functions. Maximizes safety.
Data Communication Management: Utilizes 485 communication for precise data transmission and accurate temperature control, enabling real-time battery status monitoring.
Battery Performance: The battery pack has good safety and low-temperature discharge performance, with a discharge capacity of over 90%.
