Product Details:
Cell Model: 18650/3.6V/3.35Ah
Battery Configuration: 18650/7S12P/25.2V/40Ah
Nominal Voltage: 25.2V
Nominal Capacity: 40Ah
Charging Voltage: 29.4V
Charging Current: ≤10A
Discharging Current: 10A
Instantaneous Discharging Current: 35A
Discharging Cut-off Voltage: 19.6V
Finished Product Internal Resistance: ≤200mΩ
Battery Weight: 6kg
Product Size: 260×170×90mm (Max)
Charging Temperature: 0～45℃
Discharging Temperature: -20～50℃
Storage Temperature: -20～40℃
Temperature Protection: 65℃±5℃
Battery Casing: Cold-rolled sheet metal
Lithium Battery Protection: Short Circuit Protection, Overcharge Protection, Over-discharge Protection, Overcurrent Protection, Temperature Protection
Application Field: Robots, AGV
Product Features:
Shock resistance: Designed with shock-absorbing structures filled inside the cold-rolled sheet metal casing to meet high safety and reliability requirements.
High current output: Capable of delivering high current output, up to 3C.
Data communication management: Utilizes a software management chip for accurate data transmission and precise temperature control, minimizing safety hazards.
Battery pack safety with temperature probe: The battery pack is equipped with a temperature probe and automatically activates protection if the temperature exceeds the set limit.
High cycle life of the battery pack, conforming to the values of low carbon, energy-saving, and environmental protection.
