25.6V 31Ah 26650 Lithium Iron Phosphate Battery for Reception Robots

Category

Nominal Voltage: 25.6V
Nominal Capacity: 31Ah
Battery Dimensions: 280×275×100mm (Max)
Charge Temperature: 0~45℃
Discharge Temperature: -20~60℃
Application Field: AGV, Robots, Reception Robots

For Energy Storage Solution Services, CONTACT US for details.

Product Details:
Cell Model: 26650/3.2V/3.5Ah
Battery Configuration: 26650/8S9P/25.6V/31Ah
Nominal Voltage: 25.6V
Nominal Capacity: 31Ah
Charging Voltage: 29.2V
Charging Current: ≤10A
Discharge Current: 10A
Instantaneous Discharge Current: 30A
Discharge Cutoff Voltage: 20V
Finished Internal Resistance: ≤200mΩ
Battery Weight: 10kg
Battery Dimensions: 280×275×100mm (Max)
Charge Temperature: 0~45℃
Discharge Temperature: -20~60℃
Storage Temperature: -20~40℃
Temperature Protection: Yes
Battery Enclosure: Sheet metal casing
Lithium Battery Protection: Short circuit protection, overcharge protection, over-discharge protection, overcurrent protection, balancing, etc.
Application Field: AGV, Robots, Reception Robots

Product Features:
Dust and Shock Resistance: Constructed with a cold-rolled steel plate shell with an internal shock-absorbing structure to achieve dust and shock resistance.
Waterproof Connectors: Utilizes waterproof connectors for safety and reliability.
High Cycle Life: The battery pack has a high cycle life, aligning with low-carbon, energy-saving, and environmental protection values.
Low-Temperature Operation: Capable of discharging in environments as low as -20°C.
