Product Details:
- Cell Model:LA148F20C/3.2V/20000mAh
- Battery Configuration:LA148F20C-2S1P/6.4V(DC12V)/20Ah
- Nominal Voltage:DC 12V stable output
- Nominal Capacity:20Ah
- Charging Voltage:DC input 12V
- Charging Current:≤2A
- Discharging Current:3A
- Instantaneous Discharge Current:10A
- Discharge Cut-off Voltage:4V
- Internal Resistance:≤120mΩ
- Battery Weight:2500g (including housing)
- Product Size:18017570mm
- Charging Temperature:-20～45℃
- Discharging Temperature:-40～55 ℃
- Storage Temperature:-20～50 ℃
- Temperature Protection:60℃±5℃
- Battery Housing:Aluminum alloy metal housing
- Li-ion Protection:Short circuit protection, overcharge protection, overdischarge protection, overcurrent protection, temperature protection, SMBUS communication protocol, etc.
- Application:Wide range of applications including emergency power supply in the wild, tablet computer power supply, special equipment testing, etc.
Product Features:
- Communication Function:SMBUS communication protocol; real-time monitoring of battery voltage, current, capacity, temperature, and other information.
- Quick Connection:Using push-pull self-locking connectors for quick, safe, and reliable connections.
- Data Communication Management:Utilizing precision ICs and TI charger management chips for accurate data transmission and precise temperature control, maximizing safety.
- Charging:Supports charging at low temperatures down to -20°C, meeting outdoor charging requirements.
