Product Details
Cell Model: 18650/2200mAh/3.6V
Battery Configuration: 18650-13S13P/48V/28.6Ah
Nominal Voltage: 48V
Nominal Capacity: 28.6Ah
Charging Voltage: 54.6V
Charging Current: ≤10A
Discharging Current: 60A
Instantaneous Discharge Current: 120A
Discharge Cutoff Voltage: 32.5V
Internal Resistance: ≤200mΩ
Battery Weight: 11Kg
Product Dimensions: 282×190×149mm (Max)
Charging Temperature: 0～45℃
Discharging Temperature: -20～55℃
Storage Temperature: -20～45℃
Battery Protection: Short circuit protection, overcharge protection, over-discharge protection, overcurrent protection, balancing, and equipped with 232 and 485 communication interfaces.
Application Fields: Industrial robots
Product Features
Current Handling: Supports continuous discharge at 60A, with short-term peak discharge up to 120A for a few minutes.
Data Communication Management: Uses imported software management chips with 232 and 485 communication functions, ensuring precise data transmission and accurate temperature control to minimize safety risks.
Cell Characteristics: Utilizes high-rate discharge cells capable of continuous high-power charging and discharging.
Long Cycle Life: The battery pack offers a high cycle life, supporting low-carbon, energy-saving, and environmentally friendly values.
