Product Details
Cell Model: LA486068/3200mAh/3.80V
Battery Specification: LA486068-1S1P/7.6V/3200mAh
Nominal Voltage: 7.6V
Nominal Capacity: 3.2Ah
Charging Voltage: 8.7V
Charging Current: ≤1.6A
Discharging Current: 3A
Instant Discharging Current: 3.2A
Cut-off Voltage: 6V
Internal Resistance: ≤150mΩ
Battery Weight: 300g
Product Size: 73×68.5×10.5mm
Charging Temperature: 0～45℃
Discharging Temperature: -10～55℃
Storage Temperature: -20～45℃
Battery Enclosure: Industrial-grade
Lithium Battery Protection: Short circuit protection, overcharge protection, over-discharge protection, overcurrent protection, balancing, IIC communication, etc.
Application Fields: Handheld tablets
Product Features
Current Handling:Maximum sustainable discharge current up to 3.2A.
Data Communication and Management:Uses imported management chips with IIC communication for accurate data transmission and precise temperature control, maximizing safety.
Cell Characteristics:Uses self-developed ultra-high capacity polymer cells.
Environmental Value:High cycle life, aligned with low-carbon, energy-saving, and environmental protection values.
